Inflating systems
At Cairgo it is possible to choose from four different inflating systems. Each with its own unique user functions. On this page we explain the different systems and you can examine the product photo graphics with associated product description.
CairgoBag inflating systems
Which inflating system to use depends on the demands of the user.
If, for example, you don't want to re-use the dunnage bag, but it needs to inflate very fast; then the FastFill system is suitable for you.
CairgoBag SuperFlow
SuperFlow
Its reusable design enables you to maximize your investment in load securement by reusing the same air bag multiple times where allowable. It's also an environmentally friendly choice for securing your load, because it's 100% recyclable.
Fast
The typical inflation time of 2 minutes can be reduced to 38 seconds (approx.)
The SuperFlow inflator is unique, utilizing both compressed and ambient air (Venturi Effect), enabling it to achieve unequalled inflation speeds.
Consistent
By setting the desired pressure on the air line regulator, you can achieve consistent inflation. No more over-inflated or under-inflated air bags.
Once the desired level of air pressure has been achieved, the SuperFlow inflator ceases to inflate the dunnage bag. This reverses the air flow and redirects it out the back of the inflator. This also indicates to the operator that the bag is properly inflated, preventing over inflation.
Reusable
By pushing our unique, patented blue valve flapper, operators can quickly deflate the dunnage bag and reposition it or store it for reuse.
Cost Effective
The SuperFlow system can be used multiple times and inflates the bag in less than half the time it normally takes. Significantly reducing the cost per use and labour costs.
CairgoBag HeavyFill
HeavyFill
This is the system which you need for heavy work. It has been designed to last for a long period of time, build to resist. The solid design is easy in use and gives the possibility to reuse the dunnage bag. You can empty the bag, both slow and rapidly, slowly to reposition the bag and rapidly to store it for reuse.
HeavyFill valve connector with quick coupling
Connector, which can be connected very quickly and directly to a basic or heavy design air tool. To connect a HeavyFill valve for inflating a dunnage bag with the CairgoBag HeavyFill inflating system.
CairgoBag FastFill
FastFill
This system is for the one-way dunnage bags. It allows the user to fill it as fast as possible and throw away afterwards. It is not possible to reuse the bag after inflation. It's a cheap and fast solution for a fast moving company.
FastFill valve connector (Mouse Tip)
Connector, which can be connected very quickly and directly to a basic or heavy design air tool. To connect a FastFill valve for inflating a dunnage bag with the CairgoBag FastFill inflating system.
